Cell Type Polycrystalline Solar Cell
Rated Maximum Power (Pmax) 100W
Tolerance 0~+3%
Voltage at Pmax(Vmp) 17.8V
Current at Pmax(Imp) 5.63A
Open-Circuit Voltage(Voc) 22.4V
Short-Circuit Current(Isc) 6.18A
Maximum System Voltage 1000VDC
Maximum Series Fuse Rating 20A
Operating Temperature -40°C to +85°C
Weight(kg) 6.9kg
Dimension(mm) 670*1000*30mm
Manufacture Warranty 10years
Performance Warranty ?90% after 10years , ?80% after 25 years
standard test condition AM = 1.5, E = 1000W/m2, TC = 25°C
The panels are packed in 3 pieces / box
